 Posted: Fri Mar 26, 2010 6:42 pm Post subject: Infrared Thermometer Gun |
 |
|
Does anyone have a recommendation on a purchase of a reasonably priced IR Thermometer Gun. I can find a lot of choices from $40 to $400. My preference is to keep it under $100 delivered. It seems appearances (plastic housings) can be deceiving as some of the $60 units look acceptable. Also do I care about the distance to target ratio 4:1, 12:1 or 50:1. I guess to answer that question you will ask me what I plan on using it for? CHT’s right now but who knows later?
Thanks,
Robin
[quote][b]
| | - The Matronics RV10-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?RV10-List |
|
|
|
| Back to top |
|
 |
AV8ORJWC
Joined: 13 Jul 2006
Posts: 1149
Location: Aurora, Oregon "Home of VANS"
|
| Posted: Fri Mar 26, 2010 7:07 pm Post subject: Infrared Thermometer Gun |
|
|
Had a need that was to read at 75' of distance. The 2 degree beam worked great for that - it was a Snap-On "Blue Point" at $99.00. For exhaust stacks, sparkplug reading CHTs and wheel bearing seizure any that provide a temperature might fill your bill. Those have been done with the cheapo Harbor Freight price point under $40.
When dressing props with tip damage, the handheld IR is great to make sure the composite resin temp does not run away. When using s.steel inserts in composite honeycomb with potting compound the exothermic can run away and the handheld can save the day. Ask Geoff what he does.
The right tool can sure make it more fun.
John
From: owner-rv10-list-server(at)matronics.com [mailto:owner-rv10-list-server(at)matronics.com] On Behalf Of Robin Marks
Sent: Friday, March 26, 2010 7:41 PM
To: rv10-list(at)matronics.com
Subject: Infrared Thermometer Gun
Does anyone have a recommendation on a purchase of a reasonably priced IR Thermometer Gun. I can find a lot of choices from $40 to $400. My preference is to keep it under $100 delivered. It seems appearances (plastic housings) can be deceiving as some of the $60 units look acceptable. Also do I care about the distance to target ratio 4:1, 12:1 or 50:1. I guess to answer that question you will ask me what I plan on using it for? CHT’s right now but who knows later?
Thanks,
Robin [quote] - The RV10-List Email Forum -[/b][/b][/b][/b][/b] --> http://www.matronics.com/Navigator?RV10-List[b] - MATRONICS WEB FORUMS -[/b][/b] --> http://forums.matronics.com[b] - List Contribution Web Site -[/b] Thank you for your generous support![/b] -Matt Dralle, List Admin.[/b] --> http://www.matronics.com/contribution[/b] [b]
| | - The Matronics RV10-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?RV10-List |
|
|
|
| Back to top |
|
|
n223rv(at)wolflakeairport
Guest
|
| Posted: Fri Mar 26, 2010 7:14 pm Post subject: Infrared Thermometer Gun |
|
|
I bought this one when it was on sale for $35 and have been very happy with it.
http://www.harborfreight.com/cpi/ctaf/displayitem.taf?Itemnumber=96451
-Mike Kraus
Sent from my iPhone
On Mar 26, 2010, at 10:41 PM, Robin Marks <robin(at)PaintTheWeb.com (robin(at)PaintTheWeb.com)> wrote:
[quote]
Does anyone have a recommendation on a purchase of a reasonably priced IR Thermometer Gun. I can find a lot of choices from $40 to $400. My preference is to keep it under $100 delivered. It seems appearances (plastic housings) can be deceiving as some of the $60 units look acceptable. Also do I care about the distance to target ratio 4:1, 12:1 or 50:1. I guess to answer that question you will ask me what I plan on using it for? CHT’s right now but who knows later?
Thanks,
Robin
| Quote: |
href="http://www.matronics.com/Navigator?RV10-List">http://www.matronics.com/Navigator?RV10-List
href="http://forums.matronics.com">http://forums.matronics.com
href="http://www.matronics.com/contribution">http://www.matronics.com/contribution
|
[b]
| | - The Matronics RV10-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?RV10-List |
|
|
|
| Back to top |
|
|
deej(at)deej.net
Guest
|
| Posted: Sat Mar 27, 2010 7:43 am Post subject: Infrared Thermometer Gun |
|
|
On 3/26/2010 10:41 PM, Robin Marks wrote:
| Quote: | Does anyone have a recommendation on a purchase of a reasonably priced
IR Thermometer Gun.
|
$20
<http://www.harborfreight.com/cpi/ctaf/displayitem.taf?Itemnumber=93983>
$25
<http://www.harborfreight.com/cpi/ctaf/Displayitem.taf?itemnumber=93984>
Check the temp range to make sure it is good for what you want to use
it for.
-Dj
--
Dj Merrill - N1JOV
Glastar Sportsman 2+2 Builder #7118 N421DJ - http://deej.net/sportsman/
Grumman Yankee Driver N9870L - http://deej.net/yankee/
| | - The Matronics RV10-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?RV10-List |
|
|
|
| Back to top |
|
|
robin(at)PaintTheWeb.com
Guest
|
| Posted: Sat Mar 27, 2010 8:54 am Post subject: Infrared Thermometer Gun |
|
|
Ok, opted for this one found on eBay. $20.00 Delivered. Excellent specs (I will upgrade if I don’t find this unit acceptable):
· Item condition: New
· Color: Yellow + Black
· Size: 152mm*130mm*38mm
· Weight: 145g
· Accuracy: ±2C / or ±2%
· Resolution: 0.1C or 0.1F
· Distance Spot Radio: 12:1
· Emissive: 0.95 (Pre-Set)
· C/F Selection function
· Auto Power Shut Off function
· Automatic data hold function
· Low battery indication
· Laser pointer for accurate target aiming
Measurement Temperature range: -32C-375C (-26 ºF ~716 ºF)
· Response Time & Wavelength: 500ms & (8-14um)
· DC 9V battery operation(9V Battery NOT included)
· Backlight selection, enable you see the temperature display at night
· Press and hold the button, this thermometer will read current surface temperature in 0.5 second
· Help you measure surface temperature of hot, hazardous or difficult to reach object without contact
| | - The Matronics RV10-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?RV10-List |
|
| Description: |
|
| Filesize: |
38 KB |
| Viewed: |
2152 Time(s) |
|
| Description: |
|
| Filesize: |
39.01 KB |
| Viewed: |
2152 Time(s) |
|
| Description: |
|
| Filesize: |
38.17 KB |
| Viewed: |
2152 Time(s) |
|
| Description: |
|
| Filesize: |
39.58 KB |
| Viewed: |
2152 Time(s) |
|
| Description: |
|
| Filesize: |
39.08 KB |
| Viewed: |
2152 Time(s) |
|
|
|
| Back to top |
|
|
partner14
Joined: 12 Jan 2008
Posts: 540
Location: Granbury Texas
|
| Posted: Sat Mar 27, 2010 8:50 pm Post subject: Infrared Thermometer Gun |
|
|
Robin... I'm guessing that for this auction they have more than just the one you bought.... if that's the case, let us know how well the unit works.
Robin, also... do you have a better idea of your schedule later this next week? Weather permitting, we will be flying in on Thursday morning. Hope to see you.
Don
--- On Sat, 3/27/10, Robin Marks <robin(at)PaintTheWeb.com> wrote:
| Quote: |
From: Robin Marks <robin(at)PaintTheWeb.com>
Subject: RE: Infrared Thermometer Gun
To: rv10-list(at)matronics.com
Date: Saturday, March 27, 2010, 9:52 AM
Ok, opted for this one found on eBay. $20.00 Delivered. Excellent specs (I will upgrade if I don’t find this unit acceptable):
· Item condition: New
· Color: Yellow + Black
· Size: 152mm*130mm*38mm
· Weight: 145g
· Accuracy: ±2C / or ±2%
· Resolution: 0.1C or 0.1F
· Distance Spot Radio: 12:1
· Emissive: 0.95 (Pre-Set)
· C/F Selection function
· Auto Power Shut Off function
· Automatic data hold function
· Low battery indication
· Laser pointer for accurate target aiming
Measurement Temperature range: -32C-375C (-26 ºF ~716 ºF)
· Response Time & Wavelength: 500ms & (8-14um)
· DC 9V battery operation(9V Battery NOT included)
· Backlight selection, enable you see the temperature display at night
· Press and hold the button, this thermometer will read current surface temperature in 0.5 second
· Help you measure surface temperature of hot, hazardous or difficult to reach object without contact
[img]cid:1.3614141577(at)web53707.mail.re2.yahoo.com[/img]
[img]cid:2.3614141577(at)web53707.mail.re2.yahoo.com[/img]
[img]cid:3.3614141577(at)web53707.mail.re2.yahoo.com[/img]
[img]cid:4.3614141577(at)web53707.mail.re2.yahoo.com[/img]
[img]cid:5.3614141577(at)web53707.mail.re2.yahoo.com[/img]
|
| | - The Matronics RV10-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?RV10-List |
|
| Description: |
|
| Filesize: |
38 KB |
| Viewed: |
2140 Time(s) |
|
| Description: |
|
| Filesize: |
39.01 KB |
| Viewed: |
2140 Time(s) |
|
| Description: |
|
| Filesize: |
38.17 KB |
| Viewed: |
2140 Time(s) |
|
| Description: |
|
| Filesize: |
39.58 KB |
| Viewed: |
2140 Time(s) |
|
| Description: |
|
| Filesize: |
39.08 KB |
| Viewed: |
2140 Time(s) |
|
_________________
Don A. McDonald
40636 |
|
