 Posted: Sun May 09, 2010 7:51 pm Post subject: Electric Boost Pump & Primer Switching |
 |
|
This is my first post, so here we go.
I want to have a single switch that controls my electric fuel pump and also allows me to activate my primer solenoid. The diagram below is my idea of on how this should work. I am using a S700-51 switch. In the first position, the electric fuel, pump in off. In the second position, the fuel pump is on. In the third position, a momentary position, both the fuel pump and the primer solenoid are on activating the primer. Will this work? Is there a another approach I should consider?
John Volkober
| | - The Matronics AeroElectric-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?AeroElectric-List |
|
| Description: |
|
| Filesize: |
4.41 KB |
| Viewed: |
1725 Time(s) |
|
|
|
| Back to top |
|
 |
user9253
Joined: 28 Mar 2008
Posts: 1938
Location: Riley TWP Michigan
|
| Posted: Mon May 10, 2010 3:05 am Post subject: Re: Electric Boost Pump & Primer Switching |
|
|
The circuit looks like it will work as planned. A small diode across the relay coil (with the arrow pointing towards positive) will help to prolong the switch life.
Joe
| | - The Matronics AeroElectric-List Email Forum - | | | Use the List Feature Navigator to browse the many List utilities available such as the Email Subscriptions page, Archive Search & Download, 7-Day Browse, Chat, FAQ, Photoshare, and much more:
http://www.matronics.com/Navigator?AeroElectric-List |
|
_________________
Joe Gores |
|
